What WiFi4 WiFi5 WiFi6 Modules Does SKYLAB Have?

2023-07-03/ By Admin

WiFi technology has been widely used in all aspects of our lives, and WiFi is the most well known technology for wireless communication solutions. The demand for IoT wireless communication technology is growing. WiFi technology has iterated from the first generation standard 802.11b to WiFi4, WiFi5, WiFi6. Wi-Fi 4 is also known as 802.11n, Wi-Fi 802.11ac is also known as Wi-Fi 5, WiFi 6 is also known as 802.11ax or IEEE802.11ax.

SKYLAB is a professional WiFi module development and production manufacturer. In this article I introduce to you WiFi4,WiFi5,WiFi6 modules commonly used in line communication solutions.

1、802.11n wireless network standard WiFi4 module

(1) SKW92A

SKW92A is a WiFi4 module developed based on MTK platform. It supports Bridge, Gateway, AP/Client, Router, 3G/4G Router 5 working modes. SKW92A data rate is 300Mbps, 2T2R wireless router module. It is extremely rich in interfaces, supporting video transmission, wireless routing and serial port pass-through.

(2) WG209

WG209 is also the MTK platform to develop WiFi4 module. It is a USB2.0 slave module with data rate of 150Mbps and 1T1R USB interface WiFi module. It can be embedded in set-top boxes, game consoles, printers, IP cameras, etc.

(3) LCS6260

LCS6260 is a small size, cost effective, low power consumption serial port pass-through module. It supports UART-WiFi-Ethernet data transmission with 150Mbps data rate. it is a 1T1R serial WiFi module that can be controlled through serial port using AT command set. the LCS6260 supports data transmissions in IoT smart home applications, intelligent control, etc.

2、WiFi5 module for 802.11ac wireless network standard

(1) SKW93A

SKW93A is a dual-chip wireless AP/Router WiFi5 module. It has a built-in 580M dual core and can work in both 2.4GHz and 5GHz dual band. SKW93A has a data rate of 733Mbps and is a 3T3R wireless routing module. It is extremely rich in interfaces, supporting video transmission, wireless routing and serial port pass-through.

(2) WG217

WG217 is a dual-band USB2.0 from WiFi5 module. It supports AP/Ad-Hoc / Infrastructure mode with a data rate of 433Mbp. WG217 is a 1T1R USB interface WiFi module which can be embedded in set-top boxes, game consoles, printers, IP cameras.

(3) WG222

WG222 is a dual-band serial WiFi + serial Bluetooth combo module. It supports UART-WiFi - Ethernet data transfer with 150Mbps data rate.WG222 can be controlled through serial port using AT command set. It supports data acquisition, data transmissions, and intelligent control in IoT smart home applications.

3、WiFi6 module of 802.11ax wireless network standard

WG236 is an industrial grade, small size WiFi6+Bluetooth combo module. Its main chip integrates complete hardware and software resources required for Wi-Fi and Bluetooth applications. wg236 can support AP and STA dual-role connection, and also supports BLE low-power Bluetooth connection. the data rate is 150Mbps in WiFi4 mode and 86Mbps in WiFi6 mode. the Bluetooth part can reach a maximum data rate of 2Mbps. The WG236 can be controlled via serial port using AT command set to support data acquisition, data transmission and intelligent control in IoT smart home applications.

SKYLAB's WiFi4 module, WiFi5 module, WiFi6 module have been mass produced. You want to have more WiFi module product information consult the official website customer
