Start of the revolution: 80211bgn

The story begins with the release of the 80211bgn UART WIFI module, based on a 32bit MCU SoC. It comes to add wireless connectivity to electronic systems and to design low-cost IoT systems.

80211bgn UART WIFI Module

Why this module has a powerful processing capacity?

Thanks to which it is possible to connect, through its GPIO pins, various peripherals including sensors and other compatible devices. It is difficult to use and perfect to be common for the construction of compact devices.

This is able to program as a real development board. It can common as a Wireless-Serial adapter with an SPI / SDIO type connection.

Why it is an 80211bgn UART WIFI module with a thousand uses?

It gives the possibility of being able to customize both the part concerning the software and the hardware. Moreover, it is a module with a thousand uses, making it excellent for network applications. Thanks to its high energy efficiency with the possibility of setting three modes: active mode, mode sleep and deep sleep mode.

The module minimizes its functions by deactivating the non-essential ones. It consumes just under 12uA.

80211bgn modules are available in different formats

As can be deduced from the following image, the main difference between these modules is the format and distribution of the GPIO pins. Which in 80211bgn UART WIFI module have all been made available while in others? It is possible to take advantage of only some.

In most of them, the antenna includes directly in the printed circuit board, but for example in the ESP-05 version. You need to connect an external antenna.

80211bgn based on what your design needs are?

80211bgn can be common as an external WIFI module, using the standard AT command set firmware by connecting it to any microcontroller via serial UART or directly as a WIFI enabled micro controller, programming new firmware using the provided SDK.

This board is mainly common in 80211bgn UART WIFI module, where we want to add connectivity for example to an Arduino project. Moreover, a wide adoption has facilitated by the very modest price, ranging from 2 to 10 € depending on the features offered by the manufacturers.

Applications of UART WIFI module

This module is widely common in many projects with the intention of WIFI functionality; however the following are the main applications.

  • Wireless Web Server
  • Geolocation with ESP8266
  • Pressure sensors on railway tracks
  • Air pollution meter
  • Temperature recording system
  • The smallest IoT project in the world
  • Wi-Fi controlled robot
  • Humidity and temperature monitoring
  • M2M with ESP8266

Evolution in 80211bgn UART WIFI module

A few years after the release of the 80211bgn, after a long test phase its successor was born. The most interesting evolution lies in the fact that there are more GPIO pins with which to develop more complex projects without having to resort to a GPIO expander.

At this point, check that the model you have chosen firmly anchor to the case and close the panel. The game is done! When your PC starts you will simply have to perform the driver installation procedure.

Moreover, setup is intuitive and takes no more than ten minutes. Finally, restart your PC to make sure you have activated the new hardware correctly.
