Camera WIFI Module


TUYA Intelligent Video Surveillance Camera WIFI Module T3136

Working temperature -20~55°C
Power Supply 12VDC/5VDC
Size 54*38*1.6MM
Read More

TUYA Intelligent Video Surveillance Camera WIFI Module T3136Graffiti intelligent video surveillance camera WIFI module product features are as follows

TUYA intelligent video surveillance camera WIFI module product features are as follows:

◆ capillary exposed copper heat dissipation design, better high temperature resistance

◆ adapt to the housing structure wide installation more convenient and fast

◆High compression algorithm, low bit rate transmission, more stable images

◆ online remote firmware upgrade, convenient maintenance synchronous update with a better experience

◆adapt to a variety of light board single light, double light flexible configuration

◆support 2.4G WIFI (IEEE802.11b/g/n) intelligent configuration, hotspot, two-dimensional code and other flexible network allocation

◆Support single and two-way voice intercom

◆AI intelligent pedestrian detection alarm

◆ Support TF (up to 128G) and cloud storage

Specifications 3 million
CPU XBurst core 1.5GHZ T31
Sensor 1/3 SC2336
Video frame rate 15-30FPS
Compression method SMART H.264
Resolution 2304*1296
image Supports image flipping
Light source mode Intelligent infrared, full color, dual light
Audio Frequency Input/Output Unidirectional/bidirectional voice intercom
Compression method G711U
adjust modulation
Network WIFI 2.4G WIFI(IEEE802.11b/g/n)
Ethernet 10/100Mbps
IP address Dynamic configuration
Call the police Alarm detection Movement, human form detection, area, pedestrian movement tracking
Alarm notification Mobile phone, SMS
Alarm linkage Capture, video, sound prompts
Privacy mode Off/On



Power Supply 12VDC/5VDC
Key reset
Ethernet support
Work Environment


working temperature Temperature -20~55 ° C Humidity 0~90%
Storage temperature Temperature -20~70 ° C Humidity 0~90%
Appearance parameters size 54*38*1.6MM   35g
Power waste 12V/5VDC 130/280MA±10%
Other functions


Customized Intelligence Alexa、Google Home
Alarm timing interval Support hour/minute configuration alarm interval of 1/3/5 minutes
Time watermark Support (switch)
