SKG12MI-03U car integrated navigation module

SKG12MI-03U is a high-performance vehicle-mounted integrated navigation module, designed specifically for automotive navigation applications. It incorporates a high-performance multi-constellation GNSS receiver chip that supports GPS, BDS (BeiDou), GLONASS, Galileo, and QZSS, along with dual-frequency positioning (L1 + L5), 3-axis gyroscope, and 3-axis accelerometer.

Leveraging an online adaptive integrated navigation algorithm, the SKG12MI-03U delivers real-time, high-precision vehicle positioning, speed, and attitude information. Even in scenarios where GNSS signals are degraded or completely lost (such as in tunnels or underground parking), the SKG12MI-03U can independently maintain high-precision positioning and orientation using pure inertial navigation, without relying on odometer data.

The module also outputs total mileage directly, providing convenient distance measurement for navigation and fleet tracking applications.

SKG12MI-03U optimizes the sensor temperature calibration on the basis of SKG12MI-03G

Features：

◆ High-performance 3-axis gyroscope and 3-axis accelerometer

◆ Compensation for orthogonal error, temperature drift, and more

◆ Unique calibration parameters per unit to prevent counterfeit

◆ Compact, modular design saves space in user devices

◆ Plug-and-play with standard NMEA 0183 communication protocol

◆ No installation angle requirement — easy in-vehicle installation

◆ Sub-meter level navigation performance in complex environments

◆ Compliant with RoHS, FCC, and CE standards
