Industrial Drone

Manta Ray 40

VTOL Fixed-Wing Long Distance Logistics UAV Manta Ray 40

Manta Ray 40 is a drone with a multicopter and fixed-wing hybrid configuration. It incorporates both the vertical take-off and landing capabilities of a multicopter and the sophisticated aerodynamics of an airplane.

Read More
Max Payload 10KG
Flight time 75min
Dimension 3.55×2.07×0.96m

Manta Ray 40 is a drone with a multicopter and fixed-wing hybrid configuration. It incorporates both the vertical take-off and landing capabilities of a multicopter and the sophisticated aerodynamics of an airplane. Its unique blended wing body design achieves higher aerodynamic efficiency. Moreover, redundancies in both rotors and control surfaces make this system more reliable. Manta Ray is designed for middle-to-long distance end delivery mission in a variety of scenarios including plateau, mountainous areas, and island areas.

Specifications
Specifications Description
Maximum Payload 10KG
Maximum Total Takeoff Weight 38KG
Flight time 75min
Maximum Range 100KM
Cruise Speed 26M/S
Maximum altitude 4500m
Maximum pitch angle 25°
Maximum vertical climb speed 4m/s
Wind resistance Level 6
Operating temperature -15~55℃
Dimension 3.55×2.07×0.96m
Application

◆Express Delivery

◆Fresh Product Delivery

◆Medical Cold Chain

◆Safety inspection

◆Power inspection

◆Forestry application

Q&A
1. who are we?
We are based in Guangdong, China, start from 2006,sell to North America(30.00%),Eastern Europe(15.00%),Western Europe(15.00%),Northern Europe(14.00%),Oceania(5.00%),South Asia(5.00%),Domestic Market(5.00%),South America(4.00%),Southeast Asia(3.00%),Africa(00.00%),Mid East(00.00%),Central America(00.00%),Southern Europe(00.00%).
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
